New 5130ML Low-Profile Utility Tractor

Specifications

Compare >>> Select up to 2 models to compare specifications

John Deere5130ML Low-Profile Utility Tractor

Add Model --Please Select-- 5050E (Model year 2023) 5060E (Model year 2023) 5067E (Model year 2023) 5075E (Model year 2023) 5075EN (Model year 2023) 5075GL (Model year 2023) 5075GN (Model year 2023) 5075GV (Model year 2023) 5075M (Model year 2023) 5090E (Model year 2023) 5090EL (Model year 2023) 5090GN (Model year 2023) 5090GV (Model year 2023) 5095M (Model year 2023) 5100E (Model year 2023) 5100GN (Model year 2023) 5105M (Model year 2023) 5105MH (Model year 2023) 5105ML (Model year 2023) 5120M (Model year 2023) 5120ML (Model year 2023) 5130M (Model year 2023)

Add Model --Please Select-- 5050E (Model year 2023) 5060E (Model year 2023) 5067E (Model year 2023) 5075E (Model year 2023) 5075EN (Model year 2023) 5075GL (Model year 2023) 5075GN (Model year 2023) 5075GV (Model year 2023) 5075M (Model year 2023) 5090E (Model year 2023) 5090EL (Model year 2023) 5090GN (Model year 2023) 5090GV (Model year 2023) 5095M (Model year 2023) 5100E (Model year 2023) 5100GN (Model year 2023) 5105M (Model year 2023) 5105MH (Model year 2023) 5105ML (Model year 2023) 5120M (Model year 2023) 5120ML (Model year 2023) 5130M (Model year 2023)

Engine description	OOS: John Deere PowerTech™ 4045 PWL Cab: John Deere PowerTech™ 4045 PWS
Engine displacement	4 cylinders: 4.5 L 276 cu in.
Rated engine power	At 2200 rpm: 99.7 kW 130 hp
Maximum engine power	99.7 kW 135.5 hp
Rated PTO power (hp SAE)	At 2100 rpm: 84.5 kW 115 hp
Maximum PTO power
Transmission type	OOS: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper
Hydraulic pump rated output	117 L/min 31 gpm
Rear hitch category (SAE designation)	Category 2
Base machine weight
Maximum engine power PS (hp ISO) at max engine speed (EU 2016/1628)
Rated engine power PS (hp ISO) at rated engine speed (EU 2016/1628)

Description	OOS: John Deere PowerTech™ 4045 PWL Cab: John Deere PowerTech™ 4045 PWS
Engine type	4045HLV81
Engine family	NJDXL06.8309
Rated speed	2200 rpm
Aspiration	Turbocharged
Cylinders liners	Wet sleeved
Emission level	Final Tier 4
After treatment type	OOS: ERG/DOC/SCR Cab: EGR/DOC/DPF/SCR
Displacement	4 cylinders: 4.5 L 276 cu in.

Rated power	At 2200 rpm: 95.8 kW 130 hp
Rated PTO power (hp SAE)	At 2100 rpm: 84.5 kW 115 hp
Maximum PTO power
Intelligent Power Management (IPM)
Power boost	At 1900 rpm: 4 percent
Maximum engine power	99.7 kW 135.5 hp
Engine peak torque	At 1600 rpm: 541 Nm 399 lb-ft
Drawbar power
PTO torque rise	At 1600 rpm: 30 percent
Fuel injection system and control
Air cleaner type
Maximum engine power PS (hp ISO) at max engine speed (EU 2016/1628)
Rated engine power PS (hp ISO) at rated engine speed (EU 2016/1628)

Type	OOS: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R Cab: Standard: PowrQuad™ PLUS 16F/16R Optional: Powr8™ 32F/16R with creeper
Reverser	Yes
Clutch; wet/dry	Wet
Creeper	Cab: Powr8™ 32F/16R with creeper

Type	Pressure-and-flow compensated (PFC) system
Pump rated output	117 L/min 31 gpm
Available flow at a single rear SCV	100 L/min 26.4 gpm
Available flow at front SCVs
Number of rear selective control valves (SCVs)	Three
Number of mid selective control valves (SCVs)	Standard: Zero Optional: Up to Three
Number of front selective control valves (SCVs)
Joystick SCV control	OOS: Mechanical Cab: Rear SCVs: Mechanical Mid-SCVs: Electrohydraulic
Auxiliary hydraulic features
SCV control

Hitch draft control load sense type	Electrohydraulic
Remote control valves available	Three
Hitch category (SAE designation)	Category 2; convertible to 1
Maximum lift capacity behind lift points	OOS: Standard: 3164 kg 6975 lb Optional: 3569 kg 7868 lb Cab: Standard: 2720 kg 5996 lb Optional: 3122 kg 6883 lb
Lift capacity at standard frame
Sensing type	Top link
Rear axle differential lock	Electrohydraulic

Drawbar category	Category 2
Maximum vertical load	Road/field use (250-mm extended): 1450 kg 3197 lb Field use (350-mm extended): 1200 kg 2646 lb Field use (400-mm extended): 1200 kg

Type	Standard: 540/540E/1000
Engine rpm (at rated PTO speeds)	540 at 2100 rpm 540E at 1645 rpm 1000 at 2100 rpm
Economy PTO speeds
Reverse PTO speeds
Multispeed PTO option availability
Ground speed PTO option availability
PTO actuation	Electrohydraulic

Category	Cab: Category 2
Electric power
Standard lift capacity	Cab: 1780 kg (3924 lbs)
Front power take-off (PTO)	Cab: 1000 rpm (21 spline) 34.9 mm (1.375 in.)
PTO speed	Cab: 1000 at 2200 rpm

Type	Flange
Final drive type	Inboard planetary
Differential controls	Electrohydraulic
Axle type
Brakes, type and control	Hydraulic wet disc
Rear differential lock
Load rating

Type	Mechanical Front Wheel Drive (MFWD)
Front axle differential lock
Load rating

Rear	19.5L-24 in. R4 Bias
Wheel tread range	Front: 1299-1997 mm 51.1-78.6 in.
Turning radius with brakes	3.34 m 11.0 ft
Turning radius without brakes	3.8 m 12.5 ft
Central Tire Inflation System (CTIS)
Front

Tread spacing
Drive type
Track width
Mid-rollers

Primary brake (foot brake)
Secondary brake	Cab: Yes, when equipped with Hydraulic trailer brakes
Park lock
MFWD braking
Front axle brakes
Auxiliary brakes
Hydraulic trailer brakes	Cab: Optional
Pneumatic trailer brakes

Alternator size	OOS: 90 amp Cab: Standard: 120 amp ISOBUS/GreenStar™ Ready: 200 amp
Battery options	12 V
Working lights	Standard: Halogen Optional: LED
Type of bulb in headlight (Halogen, Zenon, LED)	Standard: Halogen Optional: LED
Type of bulb in beacon (Halogen, Zenon, LED)	Kit: LED
dB(A) rating for backup alarm
Total cold cranking amps

Rollover protective structure, OOS	Rigid - foldable - telescopic Foldable, two-post Platform - flat/straddle Flat Gearshift location - console/floor Floor
Seat	OOS: Low Profile Cab: Air Ride
Cab suspension
Instructional seat	Not Available
Display	OOS: Automotive style light-emitting LED instrument cluster Cab: Digital Dash Display with three liquid crystal displays (LCDs)
Radio	Optional
Inner cab volume	55 cu ft
dB(A) rating	80 dBA
Cab glass area
Safety glass rating	Tempered per SAE J673 and ECE R43-01 requirements
Front visibility

Wheelbase	OOS: 2350 mm 92.5 in. Cab: MFWD Standard: 2350 mm MFWD Narrow: 2300 mm 90.5 in.
Overall width
Overall length	OOS: 4092 mm 161 in. Cab: MFWD Standard: 4000 mm 157.5 in. MFWD Narrow: 3945 mm 155 in.
Overall height
Drawbar clearance
Front axle center
Approximate shipping weight, Open;Cab	OOS: 4209 kg 9280 lb Cab: 4826 kg 10640 lb

Base machine weight
Maximum ballast level
Maximum permissible weight

Crankcase oil volume
Fuel tank	144 L 38 U.S. gal.
Diesel exhaust fluid (DEF) tank	12 L 3.17 U.S. gal.
Cooling system
Transmission-hydraulic system

Interval for engine oil change
Interval for hydraulic/transmission oil change
Interval for engine coolant change

Loader
Lift capacity at full height
Maximum lift height
Leveling type

Guidance	Optional: AutoTrac™ with AutoTrac Basic
Telematic	JDLink™ Modem
Remote diagnostics	Yes

AutoTrac ready	Optional for cab models
ISOBUS ready	Optional for cab models
CommandCenter video inputs
Immobilizer
Side slope rating
Uphill/downhill slope rating
Country of manufacture	Saltillo, Mexico

Date collected	6-Jan-2023
